Brand: Goodwe
PRODUCT CODE: GM1000 200A

Smart Meter GM1000 GOODWE 24mm 200A

Smart Meter GM1000 GOODWE 24mm 200A

$546.00 NZD
$546.00 NZD
Sale Sold out

GoodWe GM1000 Smart Meter (24 mm, 200 A)

Overview
The GoodWe GM1000 Smart Meter is designed for residential or small commercial solar PV systems. It monitors electrical parameters such as voltage, current, power, and energy flow. The meter allows self-consumption optimization, load management, and grid export control when paired with compatible GoodWe inverters.

100 in stock

View full details

More Information

Key Features

Specifications


  • Application: Single-phase energy monitoring

  • Voltage Range: ~110 V to 240 V AC

  • Current Range: Up to 200 A

  • Current Transformer Opening: 24 mm

  • Measurements: Voltage, current, active and reactive power, power factor, frequency, and energy

  • Accuracy: Class 1 for voltage, current, and active energy; Class 2 for reactive energy

  • Communication: RS485 interface with Modbus protocol for inverter and monitoring system integration

  • Mounting: DIN-rail installation, compact modular design

  • Power Consumption: < 3 W

  • Protection: IP20, for indoor use

  • Operating Temperature: −25 °C to +60 °C

Applications


  • Real-time monitoring of energy production and consumption

  • Export control to limit surplus energy fed into the grid

  • Load management and optimization of self-consumption

  • Integration with inverter logic and energy management systems

Compatibility


  • Designed for GoodWe single-phase on-grid and hybrid inverters

  • Requires inverter or monitoring system to operate
