PV EZRACK DIAMOND MODULE FOR MT RAIL WITH M8 BOLT

Overview

The Diamond Module is a small but essential mounting accessory for the MT Rail in Clenergy PV‑ezRack solar mounting systems. It features a diamond-shaped body that fits securely into the rail slot and uses an M8 bolt to fasten clamps or other components. It ensures a stable and modular installation for solar panels.

⭐ Key Features

• Designed for MT Rail — fits perfectly into the rail channel.

• M8 Bolt Attachment — secure fastening with a standard M8 hex bolt.

• Diamond Module Shape — improves engagement with the rail slot.

• Lightweight & Compact — easy to handle and install.

• Versatile Fixing Accessory — can be used with clamps, supports, or connectors in PV‑ezRack systems.

• Corrosion-Resistant — durable for outdoor conditions.

📊 Specifications

• Product Name: Diamond Module for MT Rail with M8 Bolt

• Part Code: ER‑DM‑MT8 (typical)

• Bolt Type: Hexagon socket M8x20

• Weight: ~0.033 kg per module

• Compatibility: MT Rail and PV‑ezRack mounting hardware

• Material: Metal (steel or aluminium) with corrosion-resistant finish

🧰 Usage

The diamond module is inserted into the MT Rail channel and used to secure clamps, brackets, or other hardware with an M8 bolt. It ensures proper alignment and stability of solar panel components.
